    INTELECT NEO ULTRASOUND MODULE

    Brand: Chattanooga
    The Intelect Neo Ultrasound Module is for installation into the Intelect Neo unit to enable dual fre...
    SKU: ELS08-M
    *
    *

    The Intelect Neo Ultrasound Module is for installation into the Intelect Neo unit to enable dual frequency ultrasound. Includes head warming feature for patient comfort. Purchase Intelect Neo Ultrasound soundheads separately to suit your clinical requirements.

    Technical Specifications

    • Frequency: 1 MHz, ± 5%; 3.3 Mhz, ±5%
    • Duty Cycles: 10%, 20%, 50%, Continuous
    • Pulse Repetition Rate: 16, 48 or 100 Hz
    • Pulse Duration: 1 mSec, ±20%; 2 mSec, ±20%; 5 mSec, ±20%
    • Amplitude: 0 to 2.5 w/cm² in continuous mode, 0-3 w/cm² in pulsed modes
    • Output accuracy: ± 20%, 10% of maximum
    • Temporal Peak to Average Ratio: 2:1, ± 20%, at 50% Duty Cycle • 5:1, ± 20%, at 20% Duty Cycle • 9:1, ± 20%, at 10% Duty Cycle
    • Treatment Time: 1 to 30 min
    • Applicator Temperature: 29.4 °C - 43.3 °C (85 °F - 110 °F)

    Download Intelect Neo Ultrasound Module brochure.
